2500kg 2 ton 2.5 ton 3 ton 4 ton 5 ton China AC hand pallettruck
Details:
Capacity: From 2T to 5T
Wheel Type: PU Wheel/Nylon Wheel
Pump (Cylinder) Type: Welded/Integrated
Catalog:
Capacity | 2000kg | 2500kg | 3000kg | 5000kg |
Max Fork height (mm) | 195/185 | 195/185 | 195/185 | 200 |
Min Fork height (mm) | 85/75 | 85/75 | 85/75 | 90 |
Lifting Height (mm) | 110 | 110 | 110 | 110 |
Fork length (mm) | 1150/1220 | 1150/1220 | 1150/1220 | 1150 |
Single Fork width(mm) | 160 | 160 | 160 | 160 |
Fork overall width (mm) | 550/685 | 550/685 | 550/685 | 580/680 |
Fork wheel-single (mm) | 80X93/74X93 | 80X93/74X93 | 80X93/74X93 | 80X68 |
Fork wheel-tandem (mm) | 80X70 | 80X70 | 80X70 | 80X68 |
Steering Wheel (mm) | 180X50 | 180X50 | 180X50 | 200X50 |
Net Weight (kg) | 73-92 | 73-92 | 73-92 | 197-200 |
Qty/20 feet container(pcs) | 140-180 | 140-180 | 140-180 | 120-140 |
Application:
CE standard hydraulic hand pallet truck is the ideal "storage aid" and "handling parnter" for all manual transport tasks over short distances, excellently suitable for use on lorries, in small warehouses and markets ect.
Economical, superior cost performance, high strength C type fork, high strength welding hydraulic pressure oil cylinder, equipped with safety valve.
Feature:
Equipped with comfortable handle.
High-balanced intensifying frame.
High strength welding hydraulic pressure oil cylinder equipped with safety valve.
----------------------------
High quality integrated cast cylinder.
Oil cylinder is equipped with permanent flow valve to ensure steady descend for the goods because of overloading.
High-balanced intensifying frame.
Package:
Standard export package with kraft paper.
Strong wooden pallet or iron pallet.
